Quick Details

  • Place of Origin: Japan
  • Brand Name: NICHIA
  • Model Number: JLD4040A-N1Y
  • Type: Laser Diode
  • Package Type: Through Hole
  • Max. Forward Voltage: 5V
  • Max. Reverse Voltage: 2V
  • Max. Forward Current: 50mA
  • Max. Reverse Current: Standard
  • Color: Violet
  • Optical output power: 20mw
  • Wavelength: 400nm~410nm
  • Beam divergence in Perpendicular: 15 19 23 degree
  • Beam divergence in Parallel: 7 9 12 degree
  • Operating Temperature: -10~80 degree
  • Storage Temperature: -40~85 degree

Packaging & Delivery

Packaging Details: High Voltage Diode 405nm Laser Blue-violet
To 18-3.8mm normal package, different kinds and quantities of laser diodes, different outside package.
Delivery Detail: 1-3 days after receiving the payment

400nm~410nm  violet laser diode

Optical output power: 20mw

Brand & Model: NICHIA NDV1342



High Voltage Diode 405nm Laser Blue-violet

High Voltage Diode



Electrical and Optical Characteristics (Tc=25℃)
Parameter  Symbol  Min.  Typ.  Max. Unit
Optical Output PowerPo   -   -20  mW
Peak WavelengthLp400405410nm
Threshold Current    Ith   -1625  mA
Operating Current    Iop   -3050  mA
Slope EfficiencyCW0.9 1.31.8 W/A
Operating Voltage    Vop   -4.45V
Beam DivergencePerpendicularQv151923  °
ParallelQh7912  °

Absolute Maximum Ratings (Tc=25℃)
Parameter Symbol  Ratings  Unit
Optical Output PowerPo55  mW
LD Reverse VoltageVr (LD)2V
Operating Temperature  Tc-10~80   ℃
Storage Temperature  Tstg-40~85   ℃



High Voltage Diode



High Voltage Diode



  1. 10000 hours life  High Voltage Diode
  2. Package: 100 pcs or 200 pcs in one tray, outside packed with antistatic bag, different kinds of TO package, different sizes of trays.  High Voltage Diode
High Voltage Diode

  • Transportation terms: High Voltage Diode

 High Voltage Diode

We have our own DHL/FEDEX accounts, or you can choose other special lines or cheaper post delivery. High Voltage Diode





  • Payment terms:  High Voltage Diode

 High Voltage Diode

You can choose PAYPAL/WESTER UNION/ T/T to our bank accounts, or with ALIBABA TRADE ASSURANCE, SECURE PAYMENT.  High Voltage Diode



High Voltage Diode


  • Our company-Dongguan Lanji Photoelectricity Co.,Ltd
